Inspector Touch industrial endoscope\borescope\videoscope
The latest technology of HD imager + freely interchangeable probes
HD with the latest technology
Video imaging components
The Inspector Touch industrial videoscope is equipped with the latest high-definition video imaging components, with a resolution up to 1280x720 and available pixels up to 921,600, a high-intensity power light source, and an excellent visual processor, to provide you with clearer still pictures and videos that help operators detect defects faster and more accurately.
Advanced probe freely interchangeable technology
The probes of the Inspector Touch industrial borescope can be replaced quickly according to different working conditions. The diameter of the probe is available in 1.2mm,1.6mm,2.0mm,2.4mm,2.8mm,4.0mm, and 6mm. Different working lengths are available from 2M to 10M. Save equipment purchase costs and improve after-sales service efficiency.
Powerful and portable
Inspector Touch industrial endoscope has a built-in Intel high-performance processor, large-capacity high-speed memory, a 6-inch IPS wide-angle high-definition LCD screen, and resolution up to XVGA as 1024x768, which can easily handle various complex tasks. The system adopts a durable and ergonomically designed integrated handheld operation. The overall easy operation is convenient. Store and carry.
High-Power High-brightness LED rear design
Inspector Touch industrial videoscope is equipped with a high-power and high-brightness LED lighting source, which guarantees the lighting requirements for visual inspection in large spaces. For example, inside the gearbox of a large wind turbine or inside a gas turbine, it has a wider application space than traditional LED front light output design.
Field-based industrial design
Inspector Touch industrial videoscope takes into account the maintenance cost control in the later period
The system is built in industrial-grade materials and a durable design
Perfectly suited to the harsh industrial site testing environment
At the same time, reduce the maintenance cost of the equipment in the later stage
Reduce the difficulty and risk for maintenance personnel
Intuitive operation interface
Inspector Touch industrial endoscope was specifically designed with the Interactive software for remote visual inspection
The most commonly used functions are displayed on graphical buttons to facilitate the operator to quickly find the desired function and reduce the cost of learning, which it easy to use and practical.
Excellent depth of field Lens design
The industry’s leading customerized depth of field design can be tailored to different depths of field according to specific application requirements. For example, the depth of field can observe more tooth surface and the inside of the bearing roller, without cumbersome replacement of different depths of field Optical lenses.
Typical Depth Of View (DOV) range options as follows: 3mm-80mm,5mm-100mm,8mm-150mm,10-200mm, customized requirements acceptable.
Suitable for different Industrial sectors
Reduce potential downtime for maintenance and personal injury
Provide maximum value for asset managers
Aerospace
· Turbine and engine · Combustion chamber
· High and low pressure compressor · Wing, fuel tank
· Synthetic materials and components, etc.
Petrochemical
Boiler plant, pressure vessel · Pressure pipeline, process pipeline · Reactor, heat exchanger
Power generation
· Excess and foreign matter grabbing · Turbine blade inspection
· Generator internal inspection
· Main steam pipeline, condenser
More industry applications
· Water pump
· Engine · Generator · Gearbox · Pipeline
· Turbine blades · Compressors
