Discontinued
Spectroline PowerMAX Blue Light LED Overhead Flood Lamp
SKU:
PM-1600B
$0.00
New product
FREE Ground Shipping
FREE Calibration
FREE Accessories
Intrinsically Safe
Intrinsically Safe
Product details
Tech support available
- Product code
- PM-1600B
- Original Code
- Original Code 2
- NSN
- Product weight
- 5.00
Description
The Spectronics PowerMAX Blue Light LED Overhead Lamp from Spectroline features 16 Blue Light LEDs and can be ganged together with other PowerMAX lamps to maximize inspection options. Built-in fans keep this unit operating at the optimal tempertaure during inspections.
The nominal Steady-State for this flood lamp is 10,000 μW/cm2 at 15". Visible Light Measurement is less than 1 foot-candle (11 lux). Blue Light coverage, at 15" and at a minimum 2,000 μW/cm2, is 18" x 8" (46 x 20 cm).
Additional Info
Package Includes
- PowerMAX Blue Light LED Overhead Flood Lamp
- DF-450PM Dichroic Filter Assembly
- 127918 Particulate Air Filter
- Heavy Duty 8 ft AC Cord
- UVS-40 Spectacles
Specifications
| Model | PM-1600B |
| Nominal Steady-State Blue Light Intensity | 10,000 μW/cm2 at 15" (38 cm) |
| Blue Light Coverage Area at minimum 2,000 μW/cm2 | 18" x 8" (46 x 20 cm) |
| Visible Light Measurement | < 1 foot-candle (11 lux) |
| Light Sources | 16 Blue Light LEDs (450 nm) |
| Dimensions (L x W x H) | 5.5" x 13.75" x 6" (14 x 35 x 15 cm) |
| Weight | 9 lb (4 kg) |
| Power Requirement | AC Power (available in 100V, 120V, 230V, and 240V versions) (main AC cord supplied with unit) |
| Cooling System | Built-in Fans |
| Lamp Style | Panel flood lamp |
Features
- Cool-running design using built-in fans
- 16 powerful Blue Light LEDs for wide coverage
- Gangable with other PowerMAX lamps
- Thin-film Dichroic Lens that improves contrast and fluorescent response
