NewSonic Short Barrel Handheld UCI Hardness Measurement Probe Standard Version (NS-SSTND-HH-PROBE)

    NewSonic Short Barrel Handheld UCI Hardness Measurement Probe Standard Version
    Starting at:

    $5,245.00 1. Quote Required



    This product has been discontinued.


    • NEW Product
    • Product Codes:
      NS-2215730
    • Tech Support Available
    • Product Weight: 3.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description

    The Short Barrel Standard Handheld Probes from New Sonic are ideal for general, handheld testing procedures in production, maintenance, and quality assurance applications that require limited access for ID (Internal Diameter) measurements. NewSonic's Short Barrel Standard Handheld Probes provide accurate and reliable measurements, taking quick readings for a breadth of different measurement points during hardness testing. The Short Barrel Standard Probes are 144 mm in length, compared to its 177 mm counterpart.

    All of NewSonic's Short and Regular Barrel Standard Handheld Measurement Probes are designed to be highly accurate and guarantee repeatable results that will remain stable over a long period. Material hardness is tested using the Ultrasonic Contact Impedance (UCI) method. The standard handheld measurement probes can measure hardness on metal, industrial ceramic and, depending on the circumstance, highly heterogeneous materials, such as cast iron (spheroidal graphite cast iron GGG50).

    Measurements include the entire range of the traditional Vickers hardness scale. Ensure you have a probe for every hardness application you may have with your SonoDur 3. The Short Barrel Standard Handheld Probes expands the measurement capabilities of the SonoDur3 as well as the SonoDur2 and SonoDur-R 'Rack' and can be setup with most devices using a standard USB interface.

    If you require probes with different dimensions or test loads, contact one of our knowledgeable sales engineers and we will work directly with you to get you the probe you need.

    Specs

    Model NS-11131 NS-11132 NS-11133
    Load 10N - 1kgf 49N - 5kgf 98N - 10kgf
    Housing Stainless Steel
    Length 144 mm
