Waygate Krautkramer MSWS Phased Array Probes (MSWS-PAUT)

    Waygate Krautkramer MSWS Phased Array Probes


    Quote Required Quote Required



    This product has been discontinued.


    • Product Codes:
      115-100-010
    • Tech Support Available
    • Product Weight: 0.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description



    These MSWS Phased Array Probes feature a compact contact area, compatible with standard single-element MSWS wedges. They provide Phased Array capabilities while maintaining comparability with standard single-element MSWS probes. Available with three different connectors.


    Applications:

    • General weld inspection, smaller objects, thinner sections
    • Tubes, pipes, pressure vessels, containers
    • Pumps, vlalve housings
    • Turbine blades, shafts
    • Wheel rims

    Features

    • Small contact area
    • Fits on standard single element MSWS wedges
    • Comparable to standard single element MSWS probes with Phased Array capabilities
    • Available with 3 different connectors

    Specs

    Additional Info
