GAL Skew-T Fillet Weld Gauge (SKEW-T-FILLET)

    GAL Skew-T Fillet Weld Gauge
    Starting at:

    $23.00 1. Quote Required



    This product has been discontinued.

    ADD TO CART

    Share this product
    • Product Codes:
      CAT-9C
    • Tech Support Available
    • Product Weight: 2.00
    HAVE A QUESTION?
      Call:   1-847-577-3980
      Send an Email
       Hours:   8:00 am to 4:30 pm CST

    Description

    The GAL Skew-T Fillet Weld Gauge and Calculator are the complete package for measuring the angles of fillet welds. The gauge measures acute and obtuse sides of welds, as well as the angle of a vertical member. While acute angles can be measured with markings on the main body, a rotating plate allows the user to measure obtuse angles with ease.

    The Calculator is a compilation of mathematical relationships between throats, leg length, skew angles, and inspection dimensions. Imperial or Metric options are available.

    Features

    • Convenient locking screw
    • Rotating plate for easier measurement of obtuse angles
    • Retractable Pointer for measuring acute angles

    Videos

    Specs

    Measurement Scale Inch or Metric
    Material Stainless Steel

    Additional Info

    Brochure

    Package Includes
