Spectroline Quadran QDR-365S Standard Intensity Multi-LED

SKU: QDR-365MSBLA
$0.00

Discontinued
Spectroline Quadran QDR-365S Standard Intensity Multi-LED

Thumbnail Filmstrip of Spectroline Quadran QDR-365S Standard Intensity Multi-LED Images

    Product details

    Tech support available

    Product code
    QDR-365MSBLA
    Original Code
    QDR-365MSBL
    Product weight
    8.00
    Purchase Spectroline Quadran QDR-365S Standard Intensity Multi-LED

    Spectroline Quadran QDR-365S Standard Intensity Multi-LED

    SKU: QDR-365MSBLA

    $0.00
    This product has been discontinued.

    Description

    QUADRAN™ 365 S-Series NDT lamps feature four ultra-hi-flux UV-A LEDs plus a convenient white light LED to quickly switch between fluorescent inspection and flaw location. For increased flexibility, a unique dual-intensity feature provides high/low white light output control.

    The lamps’ broad-beam configuration produces an extremely wide coverage area, making them ideal for both hand-held and in-line applications.

    Lamps are “tuned” to provide a nominal steady-state UV-A intensity of 4,500 μW/cm2 at 15 inches (38 cm). This addresses aerospace industry concerns.

    In addition, lamps have a high/low switch to control the white light LED output.

    The QDR-365SBL is equipped with a faceplate containing integral black light filters that reduce the output of wavelengths longer than 400 nm.


    Typical wavelength output profile of QUADRAN™ 365 S-Series lamps with and without black light filters.

    Package Includes
    • FP-550 Borofloat Filter Protector
    • Faceplate
    • Rechargeable NiMH battery pack
    • AC and DC cord sets
    • Smart AC charger
    • UV-absorbing spectacles
    • Soft carrying case
    Features
    • Extremely large coverage area of up to 5 inches (13 cm), with a minimum UV-A intensity of 2,000 μW/cm2
    • Low visible light emission — less than 2 foot-candles (22 lux)
    • Conveniently located rocker switches for quick and easy control of light sources
    • Built-in fan keeps LEDs cool to maintain optimum light output during extended use
    • Rubber bumper with Borofloat® glass lens protects LEDs from damage
    • Rugged, modular construction allows for easy field serviceability
    • Lamp handle pin receptacle allows for easy attachment of various Spectroline® mounting accessories for in-line inspection applications (accessories sold separately)
    • Meet ASTM UV-A intensity and wavelength specifications for FPI and MPI
    • Certificate of compliance for both output and wavelength measurements supplied with each lamp
    • UV-absorbing spectacles and soft carrying case included

    Product details

    Tech support available

    Product code
    QDR-365MSBLA
    Original Code
    QDR-365MSBL
    Product weight
    8.00

    Product Heading content

    Model

    Nominal
    steady-state
    UV-A (365 nm)
    intensity at
    15 inches
    (38 cm) ➀

    Visible light
    measurement
    UV-A
    coverage
    area
    (at minimum
    2000 μW/cm2)
    QDR-365S
    4,500  μW/cm2
    maximum ➁
    < 2 foot-candles
    (22 lux)
    5 in
    (13 cm)





    Light Source: 4 UV-A LEDs, 1 White Light LED


    Lamp Style: Pistol Grip


    Lamp Head (WxH): 6 x 5.5 in (15 x 14 cm)


    Length: 10 in (25 cm)


    Weight: 3 lb (1.36 kg)


    White Light LED Intensity:
         High setting: 300 foot-candles (3,229 lux)
         Low setting: 10 foot-candles (108 lux)



    Power Requirement

    AC lamp
    (QDR-365S, QDR-365SBL) 120VAC* power cord supplied with lamp


    AC/DC lamp
    (QDR-365MS, QDR-365MSBL) 120VAC*/12VDC


    Battery Pack:

    Type
    12V, NiMH (rechargeable)


    Run time
    4.5 hours (continuous)


    Charge time
    2 hours
