Spectroline Quadran QDR-365A Dual Intensity Multi-LED (QDR-365MBLA)

    Spectroline Quadran QDR-365A Dual Intensity Multi-LED




    DISCONTINUED
    Click Here to view the product that replaced this product.

    This product has been discontinued.
    Click Here to view the replacement product.


    Share this product
    • Product Codes:
      QDR-365MBLA
    • Original Code:
      QDR-365MBL
    • Tech Support Available
    • Product Weight: 8.00
    HAVE A QUESTION?
      Call:   1-847-577-3980
      Send an Email
       Hours:   8:00 am to 4:30 pm CST

    Description

    QUADRAN™ 365 Series NDT lamps feature four ultra-hi-flux UV-A LEDs plus a convenient white light LED to quickly switch between fluorescent inspection and flaw location. A unique dual-intensity feature provides both high and standard UV-A and white light output for added versatility.

    The lamps’ broad-beam configuration produces an extremely wide coverage area, making them ideal for both handheld and in-line applications.

    When the QDR-365 is in high intensity mode, the lamp provides a nominal steady-state UV-A intensity of 8,000 μW/cm2 at 15 inches (38 cm).


    When switched to the standard intensity mode, the QDR-365 provides a nominal steady-state UV-A intensity of 4,500 μW/cm2 at 15 inches (38 cm).

    In addition, the lamp has a high/low switch to control the white light LED output.
    UV-A Beam Profile



    As the wavelength of the QUADRAN™ 365 moves into the visible light range, the black light filters significantly reduce the output of the lamp at 400 nm.
    Typical wavelength output profile of QUADRAN™ 365 Series lamps with and without black light filter.






    Features

    Quadran 365 Dual Intensity Multi-LED Battery Powered Broad-Beam Lamp Features:

    • Dual-intensity capability: High setting produces a nominal steady-state UV-A intensity as high as 8,000 μW/cm2; standard setting produces a nominal steady-state intensity of 4,500 μW/cm2, both at 15 inches (38 cm)
    • Extremely large coverage area of up to 6 inches (15 cm), with a minimum UV-A intensity of 2,000 μW/cm2
    • Low visible light emission — less than 2 foot-candles (22 lux)
    • Conveniently located rocker switches for quick and easy control of light sources
    • Built-in fan keeps LEDs cool to maintain optimum light output during extended use
    • Rubber bumper with Borofloat® glass lens protects LEDs from damage
    • Rugged, modular construction allows for easy field serviceability
    • Lamp handle pin receptacle allows for easy attachment of various Spectroline® mounting accessories for in-line inspection applications (accessories sold separately)
    • UV-absorbing spectacles and soft carrying case included

    Package Includes

    • Quadran 365 Dual Intensity Multi-LED Battery Powered Broad-Beam Lamp
    • FP-550 Borofloat Filter Protector
    • Faceplate
    • Heavy Duty 8 Foot Cord
    • UVS-30 UV Absorbing Spectacles
    • Soft Carrying Case
