Spectroline PowerMAX™ 365 Black Light Filter High Intensity

Designed Specifically for NDT Professionals!

PowerMAX™ 365 Series flood lamps feature a panel of 16 powerful UV-A (365 nm) LEDs specially engineered for non-destructive testing applications. These versatile, stationary light sources can be installed overhead or in-line, and can be ganged together to provide an even wider coverage area.

PowerMAX™ 365 Series UV-A LED panel flood lamps are available in two high-intensity models that are specifically designed for NDT inspection applications requiring high UV-A output.

Ideal for NDT inspection booths, fluorescent penetrant and magnetic particle inspection, screening of fluorescent particles, wash station inspection and many other applications requiring maximum uniformity of UV-A coverage over a large area.

The PM-1600BLH is equipped with a black light filter that reduces the output of wavelengths longer than 400 nm. It provides a nominal steady-state UV-A intensity of  6,500 μW/cm² at 15 inches (38 cm).



Typical wavelength output profile of PowerMAX™ 365 Series with and without black light filter.



As the wavelength of the PowerMAX™ 365 moves into the visible light range,
the black light filter significantly reduces the output of the lamp at 400 nm.

For applications requiring extremely large coverage areas, the PowerMAX™ 365 can be quickly ganged together longitudinally (left) or back-to-back (right) using customized, easy-to-install connecting plates and brackets.

Features:

• Choice of two high-intensity models with a nominal steady-state UV-A intensity as high as 8,000 μW/cm² or two standard-intensity models with a maximum UV-A intensity of 4,500 μW/cm² at 15 inches (38 cm)
• Large coverage area of 15 inches by 6 inches (38 cm x 15 cm), with a minimum UV-A intensity of 2,000 μW/cm²
• Low visible light emission – less than 2 foot-candles (22 lux)
• Easily mountable for overhead inspection or in-line applications
• Built-in fans keep LEDs cool to maintain optimum light output during extended use
• Meets ASTM UV-A intensity and wavelength specifications for FPI and MPI
• Customizable! Multiple lamp units can be �ganged"e; together longitudinally or back-to-back for a larger coverage area to meet your specific inspection requirements
• Both high- and standard-intensity versions available with or without black light filter
• Certificate of compliance for both UV-A output and wavelength measurements is supplied with each unit
