MagnaFlux Sono 1100 High-Temperature Ultrasonic Couplant

SKU: MF-30
$713.00

MagnaFlux Sono 1100 High-Temperature Ultrasonic Couplant

Thumbnail Filmstrip of MagnaFlux Sono 1100 High-Temperature Ultrasonic Couplant Images

    Product details

    Tech support available

    Product codes
    MF-30-6XT04, MF-30-901, MF-30-6XT05
    Product weight
    2.00
    Purchase MagnaFlux Sono 1100 High-Temperature Ultrasonic Couplant

    MagnaFlux Sono 1100 High-Temperature Ultrasonic Couplant

    SKU: MF-30

    $713.00
    This product has been discontinued.

    Description

    Sono 1100 provides coupling for high-temperature thickness gauging and will maintain acoustic coupling at high temperatures beyond 15 seconds to give ample time to obtain thickness readings. In most cases, the signal strength increases with time to the point of the couplant’s thermal decomposition.

    Recommended temperature range is 700 to 775°F / 371 to 413°C

    APPLICATIONS: Corrosion testing, High temperature ultrasonic testing, Thickness gauging

    SPECIFICATIONS COMPLIANCE: API, ASME, AWS
    Additional Info

    Product Data Sheet

    Safety Data Sheet

    Package Includes
    Features
    • Extended open time window for longer inspections or to optimize thickness readings at high temperatures
    • Medium viscosity paste
    • Non-toxic, non-irritating formula
    • Excellent corrosion inhibition
    Videos

    Product details

    Tech support available

    Product codes
    MF-30-6XT04, MF-30-901, MF-30-6XT05
    Product weight
    2.00

    Product Heading content

    Technical Specifications
    Thickness Gaging *
    (Less than 15 Second Contact)    		 700° to 1,100° F
    370° to 593° C
    Smoke Point
    (Dense Plume)    		 850° F
    454° C
    Auto-Ignition Temperature

    1040° F

    560° C
    Viscosity** >3,000,000 cps
    Water soluble NO
    Humectant NO

    * A couplant's upper temperature range for short duration thickness gaging is higher than when used for flaw detection. When testing on vertical or overhead surfaces, a thicker grade of couplant is likely to stay in place, but thinner grade generally performs better on flat surfaces. No Sonotech couplants contain perfluorocarbons; thus "polymer fume fever" is not an operator hazard. Hot couplants can cause burns; therefore, gloves and goggles are recommended when working with hot surfaces.

    ** Viscosity equivalents: 4,000k = thick paste, 550k = stiff gel, 150k = pourable gel, 20k = thick liquid
