DeFelsko PosiTest HHD C Wand-style, Continuous DC High-voltage Holiday Detector Kit (HHDCKIT)

    DeFelsko PosiTest HHD C Wand-style, Continuous DC High-voltage Holiday Detector Kit
    Starting at:

    $2,995.00 1. Quote Required



    This product has been discontinued.


    • NEW Product
    • Product Codes:
      HHDCKIT
    • Tech Support Available
    • Product Weight: 13.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description

    Introducing the PosiTest HHD C Compact Wand Style - Revolutionize Your Holiday Detection Efforts

    Upgrade your holiday detection with the cutting-edge PosiTest HHD C Compact Wand Style. This advanced device sets a new standard in accuracy and reliability, ensuring you can detect holidays effectively using continuous DC technology. Say goodbye to guesswork and elevate your inspection process to a whole new level.

    The PosiTest HHD C Kit takes your holiday detection to the next level by including all the exceptional features mentioned above, giving you the ultimate toolkit for precise and efficient inspections.

    Experience unmatched comfort and convenience with the lightweight, one-piece ergonomic design of the PosiTest HHD C Compact Wand Style. Designed for all-day use, this device reduces operator fatigue, allowing you to perform inspections comfortably and without interruptions. Bid farewell to the hassle of carrying a shoulder bag, as all the electronics, batteries, and connectors are integrated into a single handheld wand. Enjoy hassle-free mobility and focus on your inspections with ease.

    Tailor the voltage range to suit your specific needs with the user-adjustable feature, offering a range from 0.5 to 30 kV. This flexibility ensures you can fine-tune your holiday detection on various surfaces and environments, providing accurate results every time.

    With the powerful Li-ion batteries neatly fitted within the compact wand handle, the PosiTest HHD C eliminates the need for a separate battery box. This reduces weight and minimizes operator fatigue, allowing you to work efficiently and effectively. Stay powered up and in control of your inspections without any hassle.

    To expand your reach and enhance accessibility, the PosiTest HHD C offers a 43 cm (17") extension rod. This extension lets you easily detect holidays on floors and other hard-to-reach areas, ensuring comprehensive coverage and thorough inspections.

    The PosiTest HHD C Compact Wand Style is designed to meet your needs precisely. With its compact dimensions of 33 cm x 10.8 cm x 8 cm (13" x 4.25" x 3.1") and a unit weight of 7.4 kg (1.63 lbs.) with batteries (no electrodes), this device is portable, easy to handle, and perfectly suited for on-the-go inspections.

    Upgrade your holiday detection process with the PosiTest HHD C Compact Wand Style. Its advanced features, ergonomic design, and exceptional performance will streamline your inspections, ensuring accurate results and improved efficiency. Stay ahead of the curve and make your inspections a breeze with this reliable and innovative device.

    Compatible with the same wide range of spring and brush electrodes as the PosiTest HHD.

    Industry-standard connectors and adaptors for compatibility with nearly all existing electrodes from other manufacturers.

    Features

    • Conforms to national and international standards including ISO, ASTM, and NACE
    • Rugged, environmentally sealed ABS plastic enclosure
    • Weatherproof, dustproof, and shockproof (minimizing creep distance to high-voltage components
    • Built-in certified voltmeter displays and regulates the voltage at the electrode
    • Regulated pulse DC voltage output will not change under load
    • Voltage calculator - choose 1 of 11 international standards, input coating thickness, and have the required test voltage automatically calculated
    • Audibly and visibly alerts when flaws/holidays are detected
    • Safety trigger to help prevent accidental high-voltage generation
    • Wide range of rolling spring electrodes and wire brushes available, with custom sizes upon request

    Videos

    Specs

    Specifications

    Specifications

    PosiTest HHD Kit

    PosiTest HHD Basic Kit

    DC Output

    PosiTest HHD C Kit

    Pulsed

    Output Voltage Adjustment

    0.5 kV — 1 kV: 10 Volt Steps

    >1 kV: 100 Volt Steps

    Output Accuracy

    Continuous

    Output Voltage Range

    ±5%

    0.5 — 35 kV

    Pulse Duration

    0.5 — 30 kV

    10 μs

    Pulse Repetition Rate

    30 Hz

    Battery Size

    72 Wh Li-ion

    36 Wh Li-ion

    Typical Battery Life
    for selected rolling springs @ 10 kV
    Ø 12"
    Ø 40"
    Operating Temperature

    40 hrs.

    ---

    16 hrs.

    30 hrs.

    12 hrs.

    -20° to 60°C (-4° to 140°F)

    Unit Weight
    Case

    1.6 kg (3.6 lbs.)

    Pelican Storm extreme duty waterproof case

    Heavy duty hard-shell case

    1.5 kg (3.3 lbs.)

    Included Electrode Rod

    50 cm (20")

    13 cm (5")

    Shoulder Strap

    Included

    Optional

    Case Dimensions

    101 x 46 x 18 cm (101" x 18" x 7")

    104 x 39 x 14 cm (41" x 15.5" x 6")

    ---

    ---

    4 Li-ion 18650 Batteries

    0.74 kg (1.63 lbs.)

    46 x 33 x 18 cm (18" x 13" x 7")



    Additional Info
