Spectroline UVA Fan Cooled Lamp 100 Watt Spot 20ft Cords and Diffusing Filter (FC-100XRD)

    Spectroline UVA Fan Cooled Lamp 100 Watt Spot 20ft Cords and Diffusing Filter




    DISCONTINUED

    Click Here to view the product that replaced this product.

    This product has been discontinued.
    Click Here to view the replacement product.


    • Product Codes:
      FC-100XRD
    • Original Code:
      FC-100XRD
    • Tech Support Available
    • Product Weight: 16.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description

    World’s Lightest Fan-Cooled, Portable UV-A Lamps

    NDT inspectors find that FC-Series UV-A lamps make prolonged inspections seem much shorter because they provide cool operation and increased comfort.

    The FC-100 365nm with Cooling Fan, Transformer-Based, with 100 Watt Spot Bulb, 2F350 Diffusing Filter, Filter Protector/Stand, UVS-30 UVAbsorbing Spectacles, 8 Foot Primary and 20 Foot SecondaryCords (120V/60Hz)

    • Quiet, built-in fan dramatically reduces running temperature, provides more comfort and safety for users, and ensures long bulb life.
    • Ergonomically designed with the handle and cord at the balance point of the lamp head. As a result, the lamp can be held for long periods with little user fatigue.
    • Special remote lamp switch in the pistol grip prevents accidental shutoff, while separate fan control switch allows for safe cool-down.
    • Lamp head is housed in a super-strong engineering polymer that is dent-proof and impact-resistant. Weighs just 3 ¨ý lbs (1.6 kg).
    • Easily meets ASTM UV-A intensity specifications for FPI and MPI
    • Bulb features average rated life of 5,000 hours



    Features

    • Cool operation Built-in fan dramatically reduces running temperatures; allows faster and easier restarting of the lamp while providing safety and comfort during use
    • Super-high intensity Exceptional UV intensity exposes unprecedented view of critical indications, enabling more accurate inspection
    • Extra tough Impact Resistant, dent-proof lamp housing is made of super-strong engineering polymer
    • Superior quality Built to exacting engineering standards to meet MIL and ASTM specifications for FPI and MPI
    • Longer-lasting bulb Special Bulb-Saver™ protects the bulb from mechanical shock damage and ensures longer bulb life (average rated life is 5,000 hours)
    • Dual-purpose filter protector Vinyl-coated, stainless-steel filter protector drastically minimizes damage to the filter and also functions as a lamp stand
    • Ergonomic design Lightweight lamp head and contoured pistol-grip handle permit extended hand-held use without discomfort or fatigue
    • Hassle-free bulb/filter replacement Flexible silicone-rubber filter holder is easily removable without tools for quick bulb and filter replacement
    • Crack-resistant filter for minimizing visible light (less than 2 footcandles or 20 lux) while maximizing long wave UV irradiance
