The GAL V-WAC Gauge and 7pc Fillet Weld Set allows the user to complete an in-depth weld inspection quickly. Both Gauges are made of Stainless Steel.
The V-WAC Gauge is ideal for checking undercuts/pits to 1/4", and crowns to 1/4" by 1/64" increments with a tolerance of 0.006". Measurements are Inch (fraction), Inch (decimal), or Metric.
The 7pc Fillet Weld Gauge Set is ideal for checking leg and throat size of fillet welds. Measurements are Imperial or Metric with a choice of one-sided or two-sided markings.
| 7pc Fillet Weld Set | CAT-8 | CAT-8a | CAT-8b | CAT-8c |
| Measurement Scale | Inch | Metric | ||
| Measuring Range | 1/8" to 1" | 3 mm to 25 mm | ||
| Markings | One-sided | Two-sided | One-sided | Two-sided |
| Material | Stainless Steel | |||
| V-WAC Single Weld Gauge | CAT-5 | CAT-5D | CAT-5M |
| Measurement Scale | Inch (fraction) | Inch (decimal) | Metric |
| Measuring Range | 0" to 1/4" | 0" to 2.4" | 0 mm to 6 mm |
| Material | Stainless Steel | ||
