Seikowave 3DSL Rhino (3DSLRhino)

    Seikowave 3DSL Rhino


    Quote Required Quote Required



    • Product Code:
      3DSLRhino
    • Tech Support Available
    • Product Weight: 0.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description

    The 3DSL Rhino was developed with field inspection in mind. In addition to the imaging hardware and analysis software, field accessories are available to facilitate all damage assessment work and ensure correct measurements every time. Industry leading accuracy, precision, and resolution result in the highest quality measurements.

    With an ingress protection level of 67 (IP67) and shock protection, this rugged Rhino can be dropped in water, dropped in mud, taken out in the Canadian winter or the Arabian summer and continue taking high quality 3D images.

    The 3DSL NDT software suite, included with the 3DSL Rhino, enables complete assessment of infrastructure damage and produces damage reports that are compliant with industry standard recommendations.



    Applications

    Midstream transmission pipeline damage assessment

    • ASME B31G, modified ASME B31G, RSTRENG
    • ASME B31.8, ASME B31.4
    • Export for finite element analysis (FEA)

    Chemical and Petro-chemical plant inspection

    • API 579 complaint

    Aircraft inspection

    • SRM complaint analysis

    Bridge Inspection

    • Metal loss on bolts and gusset plates
    • Strain and deformation of gusset plates

    Weld Inspection

    Specs



    Specification Type Specification
    Data Interface IEEE 802.3 1000baseT
    Sensor Resolution 644x484
    Sensor CMOSIS CMV300
    Sensor Type CMOS Progressive
    Sensor Size Type 1/3
    Cell Size 7.4µm
    3D Acquisition Rate <90ms
    Max Frame rate at full resolution 309 fps
    A/D 12 bit / 8 bit
    On-boeard FIFP 64 MB



    3D Measurements
    System 420
    Working Distance

    360mm (minimum)

    14" (minimum)

     Measurement Volume

    200mm x 150mm x 300mm

    8" x 6" x 12"

     Resolution (Lateral) 0.4mm / 16 mils
     Resolution (Depth)

    0.05mm / 2mils



    Operating Conditions/Dimensions
     Operating Temperature

    -10°C - +40°C

    14°F - +104°F

     Power Requirements (DC)

    12VDC, AC/DC Adapter included: system may

    also be powered using a battery

     Power Consumption (12V) 25W
     Mass 2.4kg /5.3 lbs

     Dimensions

    (L x W x H in mm)

     279mm x 178 mm x 102mm

    11" x 7" x 4"

     Regulations RoHS, Class A IP67
