FW Bell 5171 Gauss Meter DC-20 kHz - No AC Adapter - Transverse Probe (415171)

    FW Bell 5171 Gauss Meter DC-20 kHz - No AC Adapter - Transverse Probe
    Starting at:

    $1,020.86 1. Quote Required



    This product has been discontinued.

    • Product Code:
      415171
    • Tech Support Available
    • Product Weight: 4.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description



    The FW Bell 5171 Gauss Meter offers the most recent design in magnetic measuring equipment. It utilizes digital signal processing technology, a world first, along with a dynamic probe correction which allows measurements from 0 - 20 kG with a basic accuracy of 1%. The 5171 Gauss Meter also includes a laboratory-friendly, 4" transverse probe (STH17-0404), detachable and made from a polypropylene material. Applications with these CE compliant meters can range from sensitive laboratory environments to rugged industrial settings.

    The 5100 Series allows the user to choose between Gauss, Tesla, or Ampere/meter readings and features a corrected analog output (±3V FS). This series also features an auto-zeroing function, auto range, relative mode, and min./max./peak hold. The 5100 Series Gauss Meters include a built-in software that eliminates the need for complex calibration procedures. The custom-formatted LCD user prompts facilitate ease of operation.

    Features

    • Transverse Probe and Zero Gauss Chamber
    • Best Accuracy in its class
    • Universal Serial Bus Interface
    • The only handheld instrument utilizing DSP (Digital Signal Processing)
    • Min./Max./Peak Hold
    • Auto Zero
    • Auto Range and Relative Mode
    • Utilizes 4 AA Batteries - with battery life of 20 hours

    Specs

    Gauss Meter Parameter Value
    Model 5171

    Basic DC Accuracy

    2%

    Display Update Rate

    4 readings/second
    Frequency DC-20 kHz
    Measuring Range 1G (low-field probe only) - 20kG
    Resolution

    1 mG - 10 G

    Display

    LCD

    Digits

    3.5
    Readings Gauss, Tesla, Amps/Meter
    Update Range 4 readings/second
    Analog Output None

    Communication Port

    None
    Operating Temperature 0°C to 50°C (32°F to 122°F)
    Storage Temperature -25ºC to 70ºC (-13ºF to 158ºF)
    Size 6.9" x 3.9" x 1.44"
    Power 4 AA batteries
    Probe Parameter Value
    Stem Length 4" ± .063"
    Stem Thickness 0.158" ± .004"
    Cable Length 1.524 m (5')
    Stem Material Polypropylene
    Corrected Linearity 1.0% / 20 kG
    Sensitivity 1X
    Operating Temperature 0ºC to +75ºC (32ºF to +167ºF)
    Frequency Response DC to 10 kHz

    Package Includes

    • 5171 RoHS Gaussmeter
    • 4" Transverse Probe (STH17-0404)
    • Zero gauss chamber
    • Instruction Manual
    • (4) AA Alkaline Batteries
    • Carrying case
    • Manufacturers Certificate
