Parker DA400 Contour Probe (DA-400-SERIES)

    Parker DA400 Contour Probe
    Starting at:

    $98.40


    This product has been discontinued.


    • Product Codes:
    • Tech Support Available
    • Product Weight: 0.00

    HAVE A QUESTION?
       Hours:   8:00 am to 4:30 pm CST

    Description

    The DA-400 Contour Probe is a portable, self-contained device engineered to generate a magnetic field on or within ferrous-magnetic materials.

    This reliable instrument integrates both selective AC and DC functions. The AC mode generates a powerful AC field for detecting surface defects and demagnetizing after inspection, while the DC mode produces a strong Half Wave Rectified DC field for identifying certain subsurface defects.

    The controls and solid-state electronics are housed within a high-impact molded casing. Articulating legs enable the AC or DC field to be precisely applied to the inspection area on nearly any surface shape, whether in the lab, factory, or field site.

    All Parker Contour Probes comply with the requirements of applicable specifications.

    • IP51
    • Versatility and powerful performance in a lightweight (8.5 lbs.) instrument
    • Constant AC or Half Wave Rectified (DC) fields with the flip of a switch for the location of surface and some sub-surface defects
    • Apply continuous fields and demagnetize too
    • Use with dry powder, wet fluorescent or visible
    • High impact molded housing
    • One year repair/replacement guarantee
    • Optional Y-400 Yoke Light where shown is available at additional cost.
    • 230VAC model available with CE certification at an additional cost

    Due to shipping regulations, aerosols must ship via ground delivery.

    Optional Kits

    AKIT

    • Steel carrying case
    • 1 lb. Red Powder
    • 1 lb. Gray Powder
    • PB-1 Applicator

    Parker A Kit for Contour Probes

    PLA KIT

    • Super tuff plastic carrying case
    • 1 lb. Red Powder
    • 1 lb. Gray Powder
    • PB-1 Applicator

    Parker PL-A Kit for Contour Probes

    Features

    • High-impact, glass-filled nylon housing
    • AC & half wave rectified (DC)
    • One year repair/replacement guarantee
    • Exceeds ASTM lifting standards

    Specs



    DA-400

    DA-400S

    A-410

    A-410S

    Physical

    10 H × 8 L × 2.25 W

    Line Voltage Single Phase 115 VAC
    50/60 Hz
    230 VAC
    50/60 Hz
    115 VAC
    50/60 Hz
    230 VAC
    50/60 Hz
    Line Current 6 A
    AC/DC
    3 A
    AC/DC
    6 A
    AC
    3 A
    AC
    Duty Cycle

    2 minutes on – 2 minutes off

    Weight 8.5 lbs (3.8 kg)
    Construction

    Glass-filled nylon housing
    10 foot (3 m) 3-wire power cord

    Span

    12 in. (305 mm) across poles

    Field AC/DC AC/DC AC AC
